20Kg Silver Melting Machine

Name: 20Kg Silver Melting Machine
Brand: IGNITE INDUCTION LLP
Price: 320000.0 INR
Availability: InStock

Price 320000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

20Kg Silver Melting Machine Specification

Product Type
Silver Melting Machine

General Use
Industrial metal melting

Material
Stainless steel body with high-grade refractory lining

Capacity
20 Kg

Weight (kg)
Approximately 48 Kg

Computerized
No

Automatic
Semi-Automatic

Control System
Digital temperature control panel

Cooling Mode
Air or Water Cooling

Working Temperature
Up to 1200C

Accuracy
2C temperature accuracy

Smelting Time
20 to 30 minutes per batch

Metals Type
Silver, Gold, Copper, Brass

Power Supply
Single Phase, 220V/50Hz

Frequency (MHz)
50 Hz

Voltage
220V

Dimension (L*W*H)
580 x 420 x 730 mm

Feature
High-efficiency heating, energy saving, low noise, compact design

Color
Silver and Blue

Insulation Type
High-temperature resistant ceramic fiber

Power Consumption
7.5 - 10 KW

Heating Element Type
Induction Coil

Noise Level
65 dB

Applicable Industries
Jewelry, Precious Metal Refining, Laboratories

Crucible Material
Graphite/Clay Graphite

Installation Type
Floor Mounted

Display Type
Digital LED temperature display

Ambient Temperature Range
0C - 40C

Safety Feature
Automatic shutoff and overheat protection

Melting Method
Induction Melting

Packing Type
Export Wooden Box

20Kg Silver Melting Machine Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
7 Gold Melting Machine Days

About 20Kg Silver Melting Machine

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Advanced Induction Heating Technology

The 20Kg Silver Melting Machine utilizes the latest induction heating technology, ensuring rapid, uniform, and energy-efficient melting of precious and non-ferrous metals. The induction coil heats the graphite crucible, melting metals in just 20-30 minutes while maintaining exceptional thermal efficiency with low noise output of only 65 dB.

Precision and Safety Redefined

Featuring a digital LED temperature display with 2C accuracy and a reliable digital control panel, precise smelting is at your fingertips. The automatic shutoff and overheat protection system ensure every batch is processed safely, minimizing operational risks and ensuring operator confidence during continuous industrial use.

Robust Construction for Industrial Demands

Built with a stainless steel body, high-grade refractory lining, and high-temperature resistant ceramic fiber insulation, this melting machine endures demanding environments in jewelry manufacturing, precious metal refining, and laboratories. Its floor-mounted, compact design and export-quality wooden packing offer maximum durability and ease of installation.

FAQ's of 20Kg Silver Melting Machine:

Q: How does the induction coil heating in the 20Kg Silver Melting Machine work?

A: The induction coil generates an alternating magnetic field, which induces electrical currents within the graphite or clay graphite crucible. This causes rapid and uniform heating, efficiently melting metals like silver, gold, copper, and brass to the desired temperature.

Q: What safety features are integrated into this silver melting machine?

A: The machine includes automatic shutoff and overheat protection systems. These features protect both the operator and equipment by stopping operation if temperatures exceed safe levels, thereby preventing accidents and extending the unit's lifespan.

Q: When should I use graphite versus clay graphite crucibles?

A: Graphite crucibles are ideal for consistent high-performance melting of metals due to their superior thermal conductivity and purity. Clay graphite crucibles provide extra resistance to oxidation and chemical wear, making them suitable for metals or processes demanding higher chemical resistance.

Q: Where is installation appropriate for this silver melting machine?

A: This model is best installed in professional industrial settings such as jewelry workshops, precious metal refineries, and laboratories. Its floor-mounted design and compact size allow it to fit comfortably into various workspace layouts.

Q: What is the process for operating the machine, from start to finish?

A: Begin by placing the metal in the crucible and setting your desired temperature on the digital control panel. The induction coil will heat the crucible, melting the metal within 20-30 minutes. Monitor the process via the LED temperature display, and upon completion, allow the machine's cooling system to stabilize temperatures before extraction.

Q: How does this machine benefit my metal melting operations compared to traditional methods?

A: Induction melting offers higher efficiency, lower energy costs, faster processing, and improved temperature control. The low noise level, compact footprint, and robust safety features make it an optimal choice for frequent, accurate, and safe metal smelting in continuous industrial use.
