Induction Based Silver Melting Machine 15Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 15Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 15Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 315000.0 INR
Availability: InStock

Price 315000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 15Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine with Tilting Unit

General Use
Silver Melting for Jewellery Manufacturing and Metal Processing

Material
Mild Steel & High Grade Insulation Materials

Capacity
15 Kg

Weight (kg)
Approx. 220 Kg

Computerized
No

Automatic
Semi-Automatic

Control System
Digital Control Panel

Cooling Mode
Water Cooled

Working Temperature
Up to 1500C

Accuracy
1C Temperature Control

Smelting Time
25-35 Minutes per Batch

Metals Type
Silver, Gold, Alloy

Power Supply
3 Phase, 380V/415V, 50/60Hz

Frequency (MHz)
20-40 KHz

Voltage
380-415 V

Dimension (L*W*H)
850 mm x 600 mm x 1000 mm

Feature
Energy Efficient, Fast Melting, Precise Temperature Control, Tilting Pouring Unit, Overheat Protection

Color
Industrial Grey & Yellow

Insulation Type
High Density Ceramic Fiber & Refractory

Ambient Operating Temperature
5C to 40C

Melting Furnace Type
Induction Heating Furnace

Water Flow Requirement
4-5 Litres/Minute

Noise Level
<70 dB

Input Power Consumption
15-18 kW

Crucible Type
Graphite Crucible Compatible

Display
Digital LED Display for Temperature

Safety Features
Overcurrent Protection, Over Temperature Alarm, Emergency Stop Switch

Tilting Mechanism
Manual Hydraulic Tilting

Application
Ideal for Bullion Dealers, Jewellery Manufacturers, Silver Refining Units

Mobility
Heavy Duty Wheels Provided for Ease of Movement

Induction Based Silver Melting Machine 15Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 15Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Advanced Induction Heating Technology

This melting furnace leverages induction heating for rapid and uniform temperature distribution, delivering efficient and controlled melting of silver, gold, and alloys. The system supports precise management via a digital control panel and LED temperature display, achieving an outstanding 1C accuracy. Its semi-automatic functionality enhances productivity while allowing hands-on supervision of the melting process.

Superior Safety and Durability

Engineered with high-density ceramic fiber and refractory insulation, the machine ensures heat retention and structural resilience. Key safety features include overcurrent protection, over-temperature alarm, and an emergency stop switch, reducing operational risks. The heavy-duty mild steel construction and industrial-grade insulation materials further bolster long-term performance and reliability in demanding environments.

User-Friendly Design and Applications

Outfitted with manual hydraulic tilting and heavy-duty wheels, the unit provides convenient handling and movement. Its water-cooled setup maintains optimal operation, requiring 4-5 litres per minute for efficient cooling. This machine is particularly suitable for jewellery manufacturing, bullion dealing, and metal refining, combining ease of use with industrial-grade capability.

FAQ's of Induction Based Silver Melting Machine 15Kg With Tilting Unit:

Q: How does the induction based melting process work in this machine?

A: The machine employs an induction heating furnace, which generates an electromagnetic field to rapidly heat the graphite crucible and melt silver or other compatible metals. This method ensures even heat distribution and energy efficiency, resulting in consistent melting quality and shorter smelting cycles.

Q: What are the main safety features provided with this melting machine?

A: Key safety features include overcurrent protection, an over-temperature alarm, and an emergency stop switch. These safeguards help prevent electrical overload, excessive heating, and enable immediate shutdown during emergencies, ensuring operator and equipment safety.

Q: When is the appropriate time to use the manual hydraulic tilting mechanism?

A: The manual hydraulic tilting mechanism should be employed after the metal has completely melted and reached the desired temperature, as indicated on the digital display. This allows safe and controlled pouring of the molten metal into molds or subsequent processing units.

Q: Where is this induction melting machine best utilized?

A: This machine is ideally suited for bullion dealers, jewellery manufacturers, and silver refining units. It is also valuable in metal processing industries where precision melting and consistent output are critical.

Q: What is the process from loading materials to obtaining the final molten metal?

A: First, load the silver or metal into the graphite crucible. Initiate the melting cycle using the digital control panel, ensuring the water cooling system is active. Monitor the temperature on the LED display. Once the correct temperature is reached, use the hydraulic tilting unit to pour the molten metal safely into molds.

Q: How does the machine ensure precise temperature control?

A: Equipped with a digital LED display and control system, the furnace achieves 1C temperature accuracy. This enables users to closely monitor and adjust settings as required, crucial for high-quality melting in jewellery and metal processing.

Q: What are the benefits of using this induction based melting machine compared to traditional methods?

A: This machine offers faster melting times, energy efficiency, and superior temperature accuracy, with enhanced safety features and user-friendly controls. The robust construction and mobility further make it suitable for demanding industrial environments, optimizing workflow and product quality.
