Induction Based Silver Melting Machine 20Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 20Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 20Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 320000.0 INR
Availability: InStock

Price 320000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 20Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine

General Use
Melting Silver and Other Precious Metals

Material
Heavy Duty Steel Body with High-Temperature Ceramics

Capacity
20 Kg per Batch

Weight (kg)
Approx. 100 kg

Computerized
No

Automatic
Semi-Automatic with Tilting Unit

Control System
Digital Temperature Controller

Cooling Mode
Water Cooled System

Working Temperature
Up to 1600C

Accuracy
1C Temperature Precision

Smelting Time
Approx. 15-25 Minutes Per Batch

Metals Type
Silver, Gold, Copper, and Alloys

Power Supply
Three Phase AC Power

Frequency (MHz)
50-60 Hz

Voltage
380-415 V

Dimension (L*W*H)
Approx. 950 x 650 x 1200 mm

Feature
Tilting Unit for Easy Pouring, Energy Efficient, Fast Melting Cycle, User Friendly

Color
Industrial Grey with Black Accents

Service Support
Onsite and Remote Assistance

Safety Features
Overheat Protection, Interlock System

Input Water Pressure
0.2-0.4 MPa

Water Flow Requirement
10-12 L/Min

Temperature Display
Digital LED Display

Crucible Capacity
20 Kg

Ambient Temperature Range
5C to 40C

Crucible Type
Graphite Crucible

Energy Consumption
Approx. 18-25 kW per Operation

Tilting Mechanism
Manual/Lever Operated

Melting Efficiency
High Thermal Conductivity

Installation Type
Floor Mounted

Noise Level
Below 70 dB

Induction Based Silver Melting Machine 20Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 20Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Efficient Melting Process

Utilizing induction technology with high thermal conductivity, the machine delivers fast melting cycles-completing each 20kg batch in just 15-25 minutes. Its graphite crucible ensures optimal heat resistance and metal purity, while the water-cooled system maintains consistent temperature control during operation.

Advanced Safety and Control

The machine integrates advanced safety systems such as overheat protection and interlock mechanisms to safeguard both the equipment and the operator. The digital temperature controller allows for precise monitoring, achieving an accuracy of 1C and a maximum temperature of up to 1600C.

Designed for Longevity and Reliability

Built with a heavy-duty steel body, high-temperature ceramics, and industrial-grade components, this melting unit offers durability even in demanding environments. Its floor-mounted design and low-noise operation (below 70 dB) make it suitable for varied industrial settings.

FAQ's of Induction Based Silver Melting Machine 20Kg With Tilting Unit:

Q: How does the induction-based melting process work in this machine?

A: The machine uses electromagnetic induction to generate heat directly within the graphite crucible, melting silver and other metals efficiently. This non-contact process ensures rapid and uniform heating, reducing smelting time and maintaining metal purity.

Q: What safety features are included in the machine for operator protection?

A: Key safety features are overheat protection, an interlock system to prevent unsafe operation, and a water-cooled body to avoid overheating. The digital temperature controller further enables precise heat regulation for safe operation.

Q: When should the graphite crucible be replaced, and how is it maintained?

A: The crucible should be inspected regularly for cracks or erosion and replaced if any damage is found. Proper maintenance includes gentle handling, gradual preheating, and avoiding overfilling-these practices prolong its lifespan, ensuring consistent melting quality.

Q: Where is the optimal installation location for this melting machine?

A: The machine should be installed on a stable, floor-mounted surface in a well-ventilated industrial environment. Ambient temperature should remain between 5C and 40C to optimize performance and reliability.

Q: What is the process for melting silver or other metals using this equipment?

A: Load the required quantity (up to 20kg) into the graphite crucible, set desired parameters on the digital controller, and initiate the induction heating. Once melting is complete, use the lever-operated tilting unit to pour the molten metal safely.

Q: How energy efficient is the machine, and what are the operational costs?

A: With energy consumption ranging from approximately 18-25 kW per operation, the machine offers fast melting cycles, which contributes to overall lower energy usage per kilogram melted, leading to cost-efficient operation for industrial users.

Q: What are the main benefits of choosing this induction-based silver melting machine?

A: Major benefits include high melting efficiency, precise temperature control, fast cycles, robust safety measures, easy tilting for pouring, and multi-metal compatibility. User-friendly controls and extensive support ensure maximum productivity for manufacturers, suppliers, and exporters.
