Induction Based Silver Melting Machine 25Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 25Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 25Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 320000.0 INR
Availability: InStock

Price 320000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 25Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine

General Use
Industrial Silver Melting

Material
Mild Steel Body with Refractory Crucible

Capacity
25 Kg

Weight (kg)
Approx. 180 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Digital Control Panel

Cooling Mode
Water Cooling

Working Temperature
Up to 1600C

Accuracy
2C

Smelting Time
30-50 Minutes per Batch

Metals Type

Power Supply
Three Phase AC

Frequency (MHz)
20-30 kHz

Voltage
380V / 415V

Dimension (L*W*H)
950 mm x 700 mm x 1200 mm

Feature
Tilting Unit for Easy Pouring, Energy Efficient, Fast Melting

Color
Blue and Grey

Melting Efficiency
Higher than Conventional Furnace

Application Area
Jewelry Manufacturing, Silver Refinery, Precious Metal Recovery

Input Current
32-40A

Noise Level
Less than 60 dB

Insulation Material
Ceramic Fiber Board

Cooling Water Flow Rate
7-10 L/min

Tilting Mechanism
Manual Tilting with Gear Support

Display Type
LED Temperature Display

Crucible Type
Graphite Crucible

Safety Features
Overheating Protection, Emergency Stop Button

Induction Based Silver Melting Machine 25Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 25Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Superior Melting Efficiency with Precise Control

This induction silver melting machine surpasses conventional furnaces in melting speed and efficiency, delivering consistent high-quality results. The LED temperature display, graphite crucible, and digital control panel enable users to monitor and adjust critical parameters, achieving an accuracy of 2C. The unit's smelting time per batch ranges from 30 to 50 minutes, making it ideal for high-throughput industrial environments.

Manual Tilting Unit for Safe and Easy Pouring

The included manual tilting mechanism, reinforced with gear support, ensures easy and safe pouring of molten silver. This ergonomic design helps minimize operator fatigue and reduces the risk of spillage, improving both safety and productivity during the pouring process. The blue and grey unit's compact footprint makes it suitable for a variety of workspace configurations.

Comprehensive Safety and Durability Features

Built with user protection in mind, this machine features an emergency stop button, reliable overheating protection, and ceramic fiber insulation to maintain operational safety. The mild steel structure combined with a refractory graphite crucible ensures longevity and consistent performance, even under intense industrial use.

FAQ's of Induction Based Silver Melting Machine 25Kg With Tilting Unit:

Q: How does the induction silver melting process work in this machine?

A: The machine uses electromagnetic induction to generate heat within the graphite crucible. This method rapidly raises the temperature up to 1600C, efficiently melting silver and other precious metals while minimizing energy loss and operational noise.

Q: What are the main benefits of the tilting unit with gear support?

A: The manual tilting mechanism with gear support allows for controlled pouring of molten silver, enhancing operator safety and reducing the risk of accidents or spills. This design also minimizes physical strain during the pouring process.

Q: Where can this machine be used effectively?

A: This induction melting unit is ideal for jewelry manufacturing workshops, silver refineries, and facilities focused on precious metal recovery. Its robust design and fast processing make it suitable for any industrial environment requiring consistent silver melting.

Q: What safety features are included in the machine?

A: Key safety mechanisms include an emergency stop button, overheating protection, and high-quality ceramic fiber board insulation. These features help safeguard both operators and equipment during operation.

Q: How is temperature monitored and controlled during the melting cycle?

A: An LED temperature display and digital control panel allow operators to monitor and set the desired temperature, with a measurement accuracy of 2C, ensuring precise control over the melting process.

Q: What is the required cooling system for continuous operation?

A: The machine uses a water cooling mode with a flow rate of 7-10 L/min to maintain optimal operating temperatures and extend the life of internal components during repeated melting cycles.

Q: Which metals can be processed, and what is the typical batch capacity?

A: The unit is designed for silver and other precious metals, with a maximum batch capacity of 25 kg per cycle. Typical smelting times range from 30 to 50 minutes depending on the load.
