Induction Based Silver Melting Machine 30Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 30Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 30Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 335000.0 INR
Availability: InStock

Price 335000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 30Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine with Tilting Unit

General Use
Melting silver and other precious metals

Material
Mild Steel Body with High-Temperature Ceramic Crucible

Capacity
30 Kg

Weight (kg)
Approx. 225 Kg

Computerized
No

Automatic
Yes

Control System
Digital Control Panel

Cooling Mode
Water Cooled

Working Temperature
Up to 1600C

Accuracy
High melting accuracy with stable temperature control

Smelting Time
20-35 Minutes per batch

Metals Type
Silver, Gold, Copper

Power Supply
Three Phase

Frequency (MHz)
50/60 Hz

Voltage
415 V AC

Dimension (L*W*H)
Approx. 1200mm x 600mm x 950mm

Feature
Energy Efficient, Tilting Mechanism, Overheat Protection, Compact Design

Color
Blue & White

Input Power
32 kW

Melting Efficiency
Greater than 95%

Induction Coil Material
Oxygen-Free Copper

Optional Accessories
Water Chiller, Vacuum Pump, Protective Cover

Ambient Operating Temperature
5C to 45C

Mobility
Fitted with Heavy Duty Castor Wheels

Safety Features
Emergency Stop, Overload and Overheat Protection

Display
Digital Temperature Display

Noise Level
Low Noise Operation

Application
Jewellery Manufacturing, Precious Metal Refining, Industrial Casting

Tilting Mechanism
Manual or Motorized Tilting for Easy Pouring

Crucible Type
Graphite or High Alumina

Induction Based Silver Melting Machine 30Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 30Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Efficient Silver Melting Technology

Harnessing induction heating and a carefully engineered oxygen-free copper coil, this melting machine achieves rapid and uniform temperatures up to 1600C, with a batch melting time of 20-35 minutes. Its energy-efficient design minimizes operational costs and maximizes productivity for bulk precious metal processing.

Precise Digital Control

The user-friendly digital control panel displays real-time temperature information, offering high accuracy and stable temperature management. This precise control minimizes waste, ensures consistent results, and supports the melting of silver, gold, and copper with confidence.

Flexible Tilting for Easy Pouring

Designed for ease of use, the machine's manual or motorized tilting unit enables safe and effortless pouring of molten metal. An emergency stop button, overload, and overheat protection systems provide an added layer of safety during operation.

FAQ's of Induction Based Silver Melting Machine 30Kg With Tilting Unit:

Q: How does the tilting mechanism enhance the operation of the melting machine?

A: The tilting mechanism, available as manual or motorized, allows for controlled and safe pouring of melted metal, thus reducing spills and labor effort during transfer into molds or casting containers.

Q: What types of crucibles are supported, and how does the choice impact the melting process?

A: The machine supports both graphite and high alumina crucibles. Graphite is excellent for rapid melting and efficient heat transfer, while high alumina offers greater durability for high-temperature operations, catering to different metal melting requirements.

Q: Where is this machine typically used and what are its main applications?

A: This induction-based melting machine is frequently used in jewellery manufacturing units, precious metal refining facilities, and industrial casting sectors for melting silver, gold, copper, and related metals efficiently.

Q: What are the main safety features, and how do they protect operators?

A: Safety features include an emergency stop button, overload protection, and overheat safeguards. These systems automatically halt operation during faults or excessive temperatures, ensuring operator safety and protecting the machine from damage.

Q: How does the water-cooled system contribute to the machine's performance?

A: The integrated water cooling helps maintain optimal operating temperature of the induction coil and other components, ensuring prolonged equipment life, minimizing downtime, and promoting consistent melting cycles.

Q: What benefits does the digital temperature display offer during operation?

A: The digital temperature display provides operators with real-time temperature monitoring, enabling precise control over the melting environment. This ensures consistent quality and helps prevent overheating of materials.
