Induction Based Silver Melting Machine 35Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 35Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 35Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 340000.0 INR
Availability: InStock

Price 340000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Induction Based Silver Melting Machine 35Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine

General Use
Industrial silver melting

Material
Mild Steel body with refractory ceramic crucible

Capacity
35 Kg

Weight (kg)
Approx 110 Kg

Computerized
Yes

Automatic
Yes

Control System
Digital PLC control panel

Cooling Mode
Water Cooling

Working Temperature
Up to 1200C

Accuracy
High precision melting

Smelting Time
10-15 minutes per batch

Metals Type
Silver

Power Supply
Three Phase AC

Frequency (MHz)
30-50 kHz

Voltage
380-415V

Dimension (L*W*H)
1000 x 700 x 950 mm

Feature
With Tilting Unit for easy pouring, Energy Efficient, Overheat Protection

Color
Industrial grey with silver accents

Protection Features
Overload, short circuit, and overheat protection

Application
Jewellery, Metal refining, Industrial foundry melting

Crucible Type
Ceramic / Graphite crucible

Phase
3-Phase power supply

Ambient Temperature
5C to 45C

Cooling Water Flow
6-8 L/min

Noise Level
<65 dB

Tilting Mechanism
Manual/Electric tilting provided

Input Current
30-40A

Operation Mode
Continuous/Batch operation

Mobility
Mounted on castor wheels for mobility

Induction Coil Material
Copper

Melting Efficiency
>95%

Water Inlet Pressure
0.2-0.3 MPa

Display
Digital temperature and operation display

Power Consumption
20-30 kW

Induction Based Silver Melting Machine 35Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
10 Days

About Induction Based Silver Melting Machine 35Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Advanced Induction Technology for Efficient Melting

Harnessing the power of copper induction coils and high-frequency electromagnetic fields, the machine ensures swift and uniform melting of silver. With a 10-15 minute melting time per batch and energy consumption of 20-30 kW, it delivers efficiency over 95%. The innovative design supports precision through digital temperature controls and advanced PLC systems, guaranteeing optimal results for industrial applications.

Flexible Tilting and Simple Operation

This melting machine comes equipped with a tilting unit, available in manual or electric configurations for safe and effortless pouring. Mounted on castor wheels, it is easily movable within industrial workshops. The machine supports both continuous and batch operation, enhancing productivity while reducing downtime. Operation is user-friendly with a digital display panel and automated safety protocols.

Safety and Durability for Industrial Use

Protection features such as overload, overheat, and short-circuit systems ensure safe operation. The durable mild steel frame and high-quality ceramic or graphite crucible are designed for reliability and longevity, making them suitable for demanding industrial environments. Water cooling maintains optimal temperatures, while the noise level remains below 65 dB, providing a comfortable workspace.

FAQ's of Induction Based Silver Melting Machine 35Kg With Tilting Unit:

Q: How does the induction based silver melting machine achieve high melting efficiency?

A: The machine uses high-frequency copper induction coils to generate uniform electromagnetic fields, ensuring even and rapid heating. Combined with precise digital temperature controls and optimized crucible design, it achieves over 95% melting efficiency for silver.

Q: What is the operational process for this induction melting unit?

A: The process involves loading silver into the ceramic or graphite crucible, selecting operation mode (continuous or batch), setting the desired temperature on the digital control panel, and initiating melting. Once complete, the tilting unit (manual or electric) facilitates safe pouring of molten silver.

Q: When should the water cooling system be activated, and what parameters should be maintained?

A: The water cooling system should be activated before starting the melting operation. Keep the cooling water flow between 6-8 L/min and ensure inlet pressure is 0.2-0.3 MPa to maintain optimal machine performance and prevent overheating.

Q: Where can this silver melting machine be effectively used?

A: This machine is suited for jewellery workshops, industrial foundries, and metal refining units. Its mobility and three-phase compatibility make it adaptable to various industrial settings across India and similar regions.

Q: What safety measures are built into the induction melting machine?

A: The unit includes multiple safety mechanisms such as overload, short circuit, and overheat protection systems. These safeguards, combined with computerized controls, prevent accidental damage and ensure operator security during large-scale silver melting.

Q: How does the digital PLC control panel benefit users in daily operation?

A: The PLC control panel offers precise monitoring and adjustment of temperature and operational parameters, enabling high-precision melting. Its digital interface streamlines process setup, enhances safety oversight, and reduces the risk of human error.

Q: What is the main benefit of the tilting unit in this machine?

A: The integrated tilting unit, available in both manual and electric models, allows for easy and controlled pouring of molten silver. This feature enhances safety, reduces spillage risk, and improves overall workflow during the metal casting or refining process.
