Induction Based Silver Melting Machine 40Kg With Tilting Unit

Send Inquiry

Request To Call Back

Induction Based Silver Melting Machine 40Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 40Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 385000.0 INR
Availability: InStock

Price 385000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 40Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine with Tilting Unit

General Use
Melting Silver for Industrial and Jewelry Applications

Material
Mild Steel Body with Ceramic Crucible

Capacity
40 Kg per batch

Weight (kg)
Approx. 230 Kg

Computerized
No

Automatic
Semi-Automatic

Control System
Digital PLC Panel

Cooling Mode
Water Cooled System

Working Temperature
Up to 1350C

Accuracy
1C Temperature Accuracy

Smelting Time
Approx. 30-45 Minutes per Batch

Metals Type
Silver, Gold, Copper, Alloys

Power Supply
Three Phase AC 380-415V

Frequency (MHz)
20-30 KHz

Voltage
380-415V

Dimension (L*W*H)
1100 x 780 x 1150 mm

Feature
Fast Melting, Energy Efficient, Tilting Mechanism for Easy Pouring, Overheat Protection

Color
Industrial Blue-Grey

Power Factor
>0.9

Ambient Temperature Range
5C - 40C

Cooling Water Flow Rate
15-20 Liters/min

Heating Efficiency
Above 95%

Water Inlet Pressure
0.1-0.2 MPa

Usage Environment
Indoor Industrial Use Only

Input Power
35-40 kW

Tilting Mechanism
Manual/Hand Wheel Controlled

Crucible Type
High Purity Graphite Crucible

Safety Features
Overheat, Overvoltage, and Water Flow Protection

Display Type
Digital Temperature Display

Noise Level
<65 dB(A)

Induction Based Silver Melting Machine 40Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 40Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Advanced Melting Efficiency

Achieving over 95% heating efficiency and a rapid smelting time of 30-45 minutes per 40kg batch, this induction melting machine maximizes productivity for medium- and large-scale silver melting operations. Its high power factor and energy-efficient design minimize operational costs while delivering consistent results.

Precise and User-Friendly Control

Equipped with a digital PLC control panel and digital temperature display, the machine provides exceptional temperature accuracy of 1C. The manual tilting mechanism ensures controlled and safe transfer of molten metal, making the operation both accessible and reliable for workshop staff.

Robust Construction and Safety

Built from industrial-grade mild steel with a ceramic-insulated graphite crucible, the machine is designed for durability and long-term use. Safety features, including overheat, overvoltage, and water flow protection, ensure safe operations in demanding industrial environments.

FAQ's of Induction Based Silver Melting Machine 40Kg With Tilting Unit:

Q: How does the manual tilting mechanism work for pouring molten silver?

A: The tilting mechanism is operated via a hand wheel which allows controlled, manual tilting of the crucible. This design ensures precise and safe pouring of molten silver into molds, minimizing spillage and operator risk.

Q: What metals and applications is this induction melting machine suitable for?

A: While optimized for silver, the machine can also melt gold, copper, and various alloys, making it ideal for industrial applications, jewelry manufacturing, and metal casting operations.

Q: What is the recommended water flow rate and inlet pressure for cooling?

A: The cooling system requires a water flow rate of 15-20 liters per minute with an inlet pressure between 0.1-0.2 MPa to maintain optimal machine temperature and performance.

Q: When should the machine be used, and what is the ideal operating temperature range?

A: The machine is intended for use indoors in an industrial setting, operating smoothly in ambient temperatures from 5C to 40C. The working temperature can reach up to 1350C for effective melting.

Q: Where can this melting machine be installed and used most effectively?

A: It is best installed in dedicated industrial workshops or factories, particularly those involved in precious metal processing, jewelry production, or small-scale metal foundries. Proper ventilation, water supply, and three-phase AC power are required for safe operation.

Q: What benefits does the induction system provide over traditional melting methods?

A: Induction heating achieves much higher efficiency, fast melting times, uniform temperature distribution, and lower noise levels (<65dB(A)). The automated controls and safety features further reduce manual labor and enhance workplace safety.

Q: How accurate is the temperature control during the silver melting process?

A: The digital PLC system provides temperature accuracy within 1C, enabling precise monitoring and control throughout the smelting process for consistently high-quality results.
