5Kg Silver Melting Machine

Name: 5Kg Silver Melting Machine
Brand: IGNITE INDUCTION LLP
Price: 280000.0 INR
Availability: InStock

Price 280000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

5Kg Silver Melting Machine Specification

Product Type
Induction Silver Melting Machine

General Use
Melting and refining precious metals

Material
Stainless Steel Outer Body, High Temperature Ceramic Crucible

Capacity
5 Kg Silver

Weight (kg)
18 Kg

Computerized
No

Automatic
Semi-Automatic

Control System
Digital Temperature Controller

Cooling Mode
Air Cooled / Fan Cooled

Working Temperature
Up to 1200C

Accuracy
1C

Smelting Time
15-20 Minutes per batch

Metals Type

Power Supply
220V AC, Single Phase

Frequency (MHz)
50 Hz

Voltage
220V

Dimension (L*W*H)
360 mm x 250 mm x 360 mm

Feature
Compact Design, Energy Efficient, Over-heat Protection, High Melting Efficiency

Color
Silver / Grey

Noise Level
65 dB

Display Type
Digital LED Display for Temperature Reading

Ambient Temperature
0C to 40C

Ambient Humidity
90% RH

Heating Element
High-grade Induction Coil

Safety Feature
Over-current and Over-load Protection System

Application
Jewelry Making, Laboratory, Industrial Use

Max Melting Time per Batch
20 Minutes

Crucible Type
Graphite/Ceramic

Input Power
3.5 kW

5Kg Silver Melting Machine Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About 5Kg Silver Melting Machine

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

Advanced Melting Technology

Using high-grade induction coil heating, the 5Kg Silver Melting Machine achieves swift and uniform melting with exceptional energy efficiency. Its precise digital temperature control ensures optimal results, making it ideal for delicate refining processes in industrial, laboratory, and jewelry-making applications.

Safety and Reliability

Designed with robust over-current and overload protection, this machine offers worry-free operation and increased safety. Its stainless steel outer body and cooling system (air/fan-cooled) ensure longevity and secure handling, even in demanding conditions with up to 90% relative humidity and temperatures from 0C to 40C.

User-Centric Operation

The machine combines semi-automatic control with an easy-to-read digital LED display, allowing users to set and monitor temperatures accurately. Its compact design, energy efficiency, and quick batch processing-melting up to 5Kg of metal in under 20 minutes-make daily operations smooth for both small workshops and larger facilities.

FAQ's of 5Kg Silver Melting Machine:

Q: How does the 5Kg Silver Melting Machine operate?

A: This machine uses a high-grade induction coil to melt metals inside a graphite or ceramic crucible. Users set the target temperature on the digital LED controller, and the induction coil rapidly heats the crucible to the desired level, allowing efficient melting within 15-20 minutes per batch.

Q: What safety features are included in this melting machine?

A: The device is equipped with over-current and overload protection systems, as well as over-heat protection. These built-in features ensure that the machine operates safely, automatically shutting off in case of electrical or thermal abnormalities.

Q: When and where can this machine be used?

A: Suitable for environments with an ambient temperature of 0C to 40C and up to 90% relative humidity, the machine is commonly used in jewelry workshops, laboratories, and small-to-medium industrial settings across India. Its stainless steel, compact design allows easy installation in various professional spaces.

Q: What metals can I refine or melt with this machine?

A: You can efficiently melt silver, gold, copper, and similar precious or non-precious metals. The high-temperature ceramic or graphite crucible, paired with precise temperature control, makes it versatile for different metal refining needs.

Q: What are the benefits of the digital LED temperature display?

A: The digital LED display offers real-time temperature readings with 1C accuracy, enhancing monitoring and control during the melting process. This allows for precise temperature management, leading to higher-quality results, especially for precious metal applications.

Q: How do I maintain and clean the machine after each use?

A: Allow the unit to cool down completely, then carefully remove and clean the crucible. Periodically check the induction coil and ventilation system, clearing any debris to ensure efficient performance. Regular maintenance preserves accuracy and extends machine lifespan.
