Induction Based Silver Melting Machine 10Kg With Tilting Unit

Name: Induction Based Silver Melting Machine 10Kg With Tilting Unit
Brand: IGNITE INDUCTION LLP
Price: 300000.0 INR
Availability: InStock

Price 300000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Induction Based Silver Melting Machine 10Kg With Tilting Unit Specification

Product Type
Induction Based Silver Melting Machine with Tilting Unit

General Use
Silver Melting for Jewellery, Industrial and Precious Metal Applications

Material
Stainless Steel Body with Refractory Lining

Capacity
10 Kg

Weight (kg)
Approx. 65 kg

Computerized
No

Automatic
Semi Automatic

Control System
Digital Temperature Controller

Cooling Mode
Water Cooled

Working Temperature
Up to 1600C

Accuracy
2C (Temperature Control)

Smelting Time
8 - 15 Minutes (Per Batch)

Metals Type

Power Supply
Electric

Frequency (MHz)
30-80 KHz

Voltage
220V/380V AC, 3 Phase, 50/60 Hz

Dimension (L*W*H)
Approx. 750mm x 420mm x 900mm

Feature
Tilting Melting Furnace, Fast Melting, Energy Efficient, Low Loss

Color
Silver/Grey

Operating Environment
Indoor Use Only

Noise Level
<65 dB

Crucible Type
Graphite Crucible

Coolant Type
Industrial Chilled Water System

Safety Features
Overheat Protection, Short Circuit Protection, Emergency Stop Switch

Tilting Mechanism
Manual or Motorized Tilting

Installation
Plug & Play Compact Design

Crucible Capacity
Up to 10 Kg Silver

Display Type
Digital LED Display for Temperature

Melting Efficiency
High (95%+)

Induction Based Silver Melting Machine 10Kg With Tilting Unit Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
10 Days

About Induction Based Silver Melting Machine 10Kg With Tilting Unit

Welcome! IGNITE Induction LLP Rajkot ..

We excited to offer you of wide range of Jewellery casting and melting systems.

We offers in machines that comes with

# IGBT technology
# Compact design
# Simple in operate
# Low maintenance
# Fast & Economical low energy consumption
# Flame less silent operation & advance controlling systems.

We are happy to serve you better as the Induction gold melting furnace is designed for melting 100grm to 150kg gold, silver and even copper etc...

Our Induction gold melting furnace is based on the latest and most advance IGBT technology, that top and speedy melting could be realized within 2-4 minutes.

IGNITE gold melting furnace is your better choice for Lab, jewellery shop and manufacturer of jewellers.

IGNITE also provides warranty and service for your valuable machines with making purchase with us.

Address: Plot No. C31-32, Unnati Industrial Zone, Near Ravki Police Station, Ravki, Rajkot, Gujarat, India 360035

Cell - 88 66 77 22 43
Cell - 95 10 67 00 04

High-Efficiency Melting for Precious Metals

Engineered for jewelry and industrial applications, this induction melting machine delivers rapid and uniform melting performance. A high melting efficiency (over 95%) ensures minimal metal loss and maximum productivity for precious metals like silver and gold. Its robust design and advanced features support demanding environments in manufacturing, export, and trading sectors.

Advanced Safety and Simple Operation

Safety features such as overheat protection, short circuit protection, and an emergency stop switch make this machine exceptionally reliable. Its plug & play design streamlines setup, while the digital temperature controller with LED display offers intuitive operation. Both manual and motorized tilting units ensure easy and safe pouring of molten metal.

Compact Design with Superior Cooling

The machine's compact footprint (approx. 750mm x 420mm x 900mm) fits neatly into indoor environments. Integrated water cooling using an industrial chilled water system maintains stable operation and prolongs equipment life, even at working temperatures reaching 1600C. The sturdy stainless steel build and refractory lining promise longevity and resilience in frequent use.

FAQ's of Induction Based Silver Melting Machine 10Kg With Tilting Unit:

Q: How does the tilting mechanism of the silver melting machine work?

A: The tilting mechanism can be operated manually or with a motor, allowing the user to safely and smoothly pour molten metal from the graphite crucible into molds or containers. Both options are engineered for stability and ease of use.

Q: What are the safety features included in this induction melting furnace?

A: Safety is ensured with overheat protection, short circuit protection, and an emergency stop switch. These features work together to prevent accidents and protect both the user and the machine during operation.

Q: When is this machine most suitable to use?

A: This machine is best used for melting silver and other precious metals, particularly in jewelry making, industrial refining, and precious metal applications. Its robust design and efficient melting process suit both small-scale and industrial environments.

Q: Where should the melting machine be installed for optimal performance?

A: The unit is intended for indoor use only. It should be installed in a well-ventilated space with sufficient water-cooling facilities, ensuring the plug & play system can be fully utilized for safe and reliable operation.

Q: What is the typical process for melting silver with this machine?

A: First, load up to 10 kg of silver into the graphite crucible. Set the required temperature using the digital controller. Once melted (within 8-15 minutes per batch), use the tilting mechanism to carefully pour the molten silver into a mold. The water-cooled system keeps temperatures stable throughout.

Q: How does using this induction melting furnace benefit silver processing?

A: The high efficiency (over 95%), fast smelting (8-15 minutes), and precise temperature control reduce energy costs and metal loss. The machine's excellent safety features and ease of use provide reliable operation and enhance overall productivity for users.
